Parts For Repair Only



Item Number
SMOTOR-SU001M


Features
12V, 1.4KW, 9TH, CW


Suit
Fit For Holden Cruze eng. M15A 1.5L 2002-2003;
Fit For Suzuki Baleno eng. G16B 1.6L 1995-2001;
Fit For Suzuki Baleno eng. 18A 1.8L 1995-2001;
Fit For Suzuki Carry Van eng. G13B 1.3L 1999-2005;
Fit For Suzuki Jimny SN413 eng. M13A, G13B 1.3L 1998-2003;
Fit For Suzuki Ignis eng. M13A 1.3L 2000-2003;
Fit For Suzuki Ignis eng. M15A 1.5L 2000-2003;
Fit For Suzuki Liana eng. M16A 1.6L 2001-2003;
Fit For Suzuki Sierra eng. G13A 1.3L 1985-1998;
Fit For Suzuki Sierra eng. G13B 1.3L 1985-1998;
Fit For Suzuki Swift eng. G16A 1.6L 1988-1998;
Fit For Suzuki Swift eng. G16B 1.6L 1988-1998;
Fit For Suzuki Swift eng. M15A 1.5L 2005-2006;
Fit For Suzuki Vitara eng. G13B 1.3L 1987-1988;
Fit For Suzuki Vitara eng. G16A 1.6L 1988-1998;
Fit For Suzuki Vitara eng. G16B 1.6L 1991-2003;
Please note this starter does not have threaded mounting holes.



NOTE: Does NOT suit Jimny models with Part Number 3110081A3 / M000T84981, check your original type or send your part number to us before placing the order.


Specifications
Volts    12V
KiloWatts    1.4KW
Teeth    9TH
Rotation    CW
Overall Length    230mm
Mounting Hole    9.2mm
Mt Holes Centre    105.5mm
Flange Diameter    66mm
Nose Cone Length    41mm
Pinon Diameter    28mm
Out of Mesh Clearance    4mm
Field Housing Diameter    76mm


Package
1 X Starter Motor



SKU SMOTOR-SU001M
Brand POWEROY
Shipping Weight 5.0000kg
Shipping Width 0.140m
Shipping Height 0.150m
Shipping Length 0.210m
Shipping Cubic 0.004410000m3
Assembled Length 0.210m
